TE D
The TE D is tailored for trays with lids, providing a seamless and efficient solution for secure packaging.
- Communicates easily with other machines in the packaging line.
- Ergonomic easy access magazine for clean release of each blank from the magazine.
- Flexible to handle different tray formats.
Lantech Tray Erectors Produce Square Trays
Lantech Tray Erectors are designed for a wide variety of tray styles and sizes. They feature an ergonomic and safe design, and produce perfectly square trays that maintain their visual appeal so your product looks great and is protected from damage.
Specifications
Performance
Throughput Speed
Up to 20 trays per minute
Tray Size Minimum (Outside Dimensions)
100 mm L x 180 mm W x 40 mm H
(4" L x 7 1/10" W x 1 3/5" H)
Tray Size Maximum (Outside Dimensions)
260 mm L x 340 mm W x 200 mm H
(10 1/4" L x 13 3/8" W x 7 7/8" H)
Machine Data
Magazine infeed Capacity
280 blanks (approximate)
Weight
725 kg (1600 lbs)
Dimensions
2730 mm L x 1580 mm W x 1800 mm H
(107 1/2" L x 62 1/2" W x 70 9/10" H)
Service Requirements
Air Supply
6 Bar (80 Psi)
Dedicated Electric Service Req. US
230V, 3-ph, 60 Hz, Wye w/Ground
Dedicated Electric Service Req. EU
3L-PE-400V-50 Hz-Neutral
Tray Criteria
Tray Types
Tray with Lid
Wave Types
E Wave or Combinations
Wall Types
Single & Double Wall (test for single wall)
Tray Closure
Tray Closure
Refer to Robatech/Nordson Manual
Warranty
Warranty Duration
3 Years, Unlimited Cycles
