Q Automatic

Home » Products » Automatic Stretch Wrappers » Q Automatic

With an operator-friendly design, the Q Automatic includes an easy to navigate touch screen, clear access to load film, and a fully guarded film roll carriage. There are no trip hazards or pinch points, and motors, wires and belts are fully enclosed.

Pallet Grip®: Locks your load to the pallet
Power Roller Stretch Plus film delivery system: Delivers better corner compensation to keep from crushing products
Industrial duty conveyor, closed space rollers and 4,000lbs capacity
PLd safety rating for electrical components; PLc safety rating for pneumatics
Complete system guarding and safety signage standard

Get a Quote

The Q Automatic Stretch Wrapper is our entry level, turntable stretch wrapper.

Comes standard with fencing and a variety of other safety features. The machine can wrap up to 45 loads per hour, and are easy to use, safe and reliable.

Available Options

LINC^® | Lantech Intelligent Network Connection^®

Upgrade your system with LINC to monitor machine data and performance from anywhere. LINC utilizes an ultra-secure connection allowing customers to react to issues before they become problems.

30” Film Delivery System
For customer applications where 30” film is used.

90 Degree Infeed Conveyor Standard Flow
With the mast at 12 o’clock product flows from 6 o’clock to 9 o’clock. Note: System speed will be decreased.

90 Degree Exit Conveyor Standard Flow
With the mast at 12 o’clock product flow is from 3 o’clock to 6 o’clock. Note: System speed will be decreased.

90 Degree Infeed Conveyor Reverse Flow
With the mast at 12 o’clock product flows from 6 o’clock to 3 o’clock. Note: System speed will be decreased.

Increase the wrap height of your loads
Replace the 2032 mm (80") mast with a 2540 mm (100") or a 3556 mm (140") mast.

Load Seeking Clamp
Eliminates the beginning film tail. Replaces the jaw clamp with a vacuum clamp that pivots out to the load.

Modular Electric Top Platen
Stabilizes tall, lightweight or unstable loads during the wrap cycle.

Pallet Grip®
Makes a "cable" of film that locks the load to the pallet. The film cable decreases the risk of damage during shipment.

Turntable Washdown
Use water at "city pressure" to clean the turntable. Make sure that the water can drain from the area.

Power Roller Stretch Plus - Film Delivery System (FDS)
Senses and adjusts the wrap force to the changes in the tension on the film. It is for a turntable speed more than 12 rpm, for very light or fragile loads, or for exact control of the wrap force.

Specifications

Performance

Production Speed

Up to 45 Loads/Hr

Maximum Load Size

1376 mm L x 1219 mm W x 2336 mm H
(54" L x 48" W x 92" H)

Minimum Load Size

914 mm L x 914 mm W x 610 mm H
(36" L x 36" W x 24" H)

Maximum Load Weight

1814 kg
(4000 lbs)

Performance Features

Pallet Grip®

Standard

Load Guardian

Not Available

Standard Film Width

500 mm (20")

Standard Pre-Stretch

225%

Wrap Force

Electronic Control

Film Capacity

254 mm Diameter, 508 mm Width
(10" D x 20" W)

Film Delivery System

Power Roller Stretch Plus

Automation Unit - Film Clamp

Reach Arm with Impulsed Hot Wire Film Cutter

Load Handling

Turntable Speed (Variable)

15 RPM

Turntable Size

1321 mm Effective Width, 2057 mm Diameter
(52" EW, 81" D)

Turntable Drive

.075 kW (1hp) 180 VDC Motor w/ Brake

Weight and Size

Approx. Shipping Weight

3289 kg (7250 lbs)

Size

5232 mm L x 3886 mm W x 3074 mm H
(206" L x 153" W x 121 1/8" H)

Service Requirements

Pneumatic

85-142 lpm @ 6Bar, 3-5 cfm @ 80 Psi, 4 Bar (55 Psi)

Dedicated Electric Service Req. US

480 V, 3ph, 60Hz, Wye w/Ground

Dedicated Electric Service Req. EU

3L-PE-400V-50Hz-No Neutral

Enclosure

NEMA 12 Enclosure with Disconnect and Safety Lock-out

Control

PLC wth HMI Touch Screen

Warranty

Warranty Duration

3 Years, Unlimited Cycles, All Components Covered
