C2000

The C2000 is a reliable, customizable, high speed case erector for 24/7 production line automation that delivers square cases with no jams.

  • Eight suction cup pick-up frame, which guarantees 90-degree case corners.
  • Ergonomic easy access magazine for clean release of each blank from the magazine
  • Communicates easily with other machines in the packaging line.

Available Options

LINC® | Lantech Intelligent Network Connection®

Upgrade your system with LINC® to monitor machine data and performance from anywhere. LINC® utilizes an ultra-secure connection allowing customers to react to issues before they become problems.

Beacon
Colored lights indicate the status of the machine, blanks supply, and tape or hot melt supply.

Non-Standard Case Dimension
Machine can be modified for a variety of case dimensions. Please contact Lantech for details.

High Speed
Increases speed to maximum of 30 cases per minute. Please contact Lantech for details

Communication
Various communication configurations possible. Please contact Lantech for details.

Stainless Steel Frame or Components
Please contact Lantech for details.

Tape Head Storage Bracket
Holds additional tape head.

75mm (3") Tape Head
Applies 750 mm (3") wide tape. Replaces standard 50 mm (2") tape head.

Extended Magazine
Increases the number of blanks the magazine holds.

Short Magazine
For application in narrow areas, decreases the number of blanks the magazine holds.

Acoustic Signal
An alarm sounds to indicate the presence of a fault condition.

Custom Options
Many options available for case types and dimensions, speeds, closing methods, machine frame and magazine, and machine performance data communications are available. Please contact Lantech Customer Support if your requirements are not satisfied by the options published on this page.

Specifications

Performance

Throughput Speed

8 Cases/Minute (25 CPM with option)

Case Size Minimum (Outside Dimensions)

200 mm L x 150 mm W x 150 mm C
(7 7/8" L x 5 7/8" W x 5 7/8" C)

Case Size Maximum (Outside Dimensions)

620 mm L x 450 mm W x 650 mm C
(24 1/2" L x 17 3/4" W x 25 5/8" C)

Machine Data

Magazine infeed Capacity

200 Cases (approximate)

Weight

825 kg
(1820 lbs)

Dimensions

2540 mm L x 2480 mm W x 1800 mm H
(100" L x 97 5/8" W x 70 7/8" H)

Outfeed height

600 mm +/- 30 mm
(23 5/8" +/- 1 1/8")

Service Requirements

Air Supply

6 Bar (80 Psi)

Dedicated Electric Service Req. US

230V, 3ph, 60Hz, Wye w/Ground

Dedicated Electric Service Req. EU

3L-PE-400V-50Hz-Neutral

Case Criteria

Case Types

RSC, HSC, FEFCO 0200/0201

Flute Types

B, C, E or Combinations

Wall Types

Single & Double Wall (test for multiple wall)

Top Seal

Tape

Lantech TH-Series

Hot Melt

Robatech/Nordson

Warranty

Warranty Duration

3 Years, Unlimited Cycles

LINC®️ | Lantech Intelligent Network Connection® Option

LINC®️ – an IoT solution is now available as an option on most C-Modular Case Erectors.

LINC allows subscribers to monitor machine data and performance in real time, from anywhere. It provides actionable intelligence and advanced analytics to support maintaining and improving system uptime, productivity, load quality, and cost, allowing customers to react to issues before they become problems.

Learn More
